| Model Number: | HH-FINEWIRE |
| MOQ: | one spool |
| Price: | contact with us |
| Payment Terms: | L/C, T/T, Western Union, Alipay |
| Supply Ability: | 3000 spool PER 30 DAYS |
| Item | Grade | Size(mm) | Size(micro) | g/spool |
|---|---|---|---|---|
| Stainless Steel Filament - 0.025mm | AISI 304/304L | 0.025mm | 25 microns | 250-600 |
| Stainless Steel Filament - 0.030mm | AISI 304/304L | 0.030mm | 30 microns | 250-600 |
| Stainless Steel Filament - 0.035mm | AISI 304/304L | 0.035mm | 35 microns | 250-600 |
| Stainless Steel Filament - 0.040mm | AISI 304/304L | 0.040mm | 40 microns | 250-600 |
| Stainless Steel Filament - 0.045mm | AISI 304/304L | 0.045mm | 45 microns | 250-600 |
| Stainless Steel Filament - 0.050mm | AISI 304/304L | 0.050mm | 50 microns | 250-600 |
| Stainless Steel Filament - 0.060mm | AISI 304/304L | 0.060mm | 60 microns | 250-600 |
| Stainless Steel Filament - 0.025mm | AISI 316/316L | 0.025mm | 25 microns | 250-600 |
| Stainless Steel Filament - 0.030mm | AISI 316/316L | 0.030mm | 30 microns | 250-600 |
| Stainless Steel Filament - 0.035mm | AISI 316/316L | 0.035mm | 35 microns | 250-600 |
| Stainless Steel Filament - 0.040mm | AISI 316/316L | 0.040mm | 40 microns | 250-600 |
| Stainless Steel Filament - 0.045mm | AISI 316/316L | 0.045mm | 45 microns | 250-600 |
| Stainless Steel Filament - 0.050mm | AISI 316/316L | 0.050mm | 50 microns | 250-600 |
| Stainless Steel Filament - 0.060mm | AISI 316/316L | 0.060mm | 60 microns | 250-600 |
The production methods of stainless steel microwire include traditional drawing and cutting method, melting and drawing method, cluster drawing method, scraping method, cutting method, etc. At present, the smallest fiber diameter can reach 0.025mm and the longest length can reach tens or even hundreds of meters.
| Grade | 304L | 316L |
|---|---|---|
| Tensile strength N/mm² | 850-970 | 740-840 |
| Electrical conductivity S*m/mm² | 1.37 | 1.33 |
| Resistance %IACS | 2 | 2 |
| Density kg/dm³ | 7.9 | 7.9 |
Textile products, Filters, Cleaning products, Aerospace, Chemical industry, Medical treatment, Electronic wires, etc.
| HK100(1) | HK100(2) | HK115 | K90*100 | PL-1 | KK80 | KK125 | |
|---|---|---|---|---|---|---|---|
| D1 | 100 | 100 | 115 | 90 | 80 | 80 | 125 |
| D2 | 74 | 74 | 88 | 60 | 60 | 53 | 80 |
| D3 | 25 | 59 | 25 | 20 | 20 | 20 | 26 |
| L1 | 160 | 160 | 140 | 120 | 120 | 100 | 160 |
| L2 | 85 | 90 | 80 | 100 | 100 | 70 | 90 |
| Weight(g) | 274 | 350 | 272 | 100 | 76 | 82 | 337 |
