| Model Number: | HH-SSPS |
| MOQ: | 3 square meters |
| Payment Terms: | ,L/C,T/T,Western Union |
| Supply Ability: | 3000 rolls per 30 days |
| Mesh/inch | Wire Dia. (μm) | Opening (μm) | Open Area (%) | Thickness (μm) | Through ink (cm³/m²) | Calender thickness (μm) |
|---|---|---|---|---|---|---|
| 80×80 | 90 | 228 | 52 | 198-207 | 103.0 | 168-170 |
| 80×80 | 120 | 198 | 39 | 276-288 | 92.9 | 228-230 |
| 100×100 | 100 | 154 | 36.8 | 230-240 | 77.2 | 188-190 |
| 120×120 | 80 | 132 | 39 | 184-192 | 65.8 | 148-150 |
| 150×150 | 60 | 109 | 41.7 | 138-144 | 50.0 | 138-142 |
| 165×165 | 45 | 109 | 50.1 | 95-104 | 45.1 | 78-80 |
| 165×165 | 50 | 104 | 45.6 | 110-115 | 45.6 | 88-90 |
| 180×180 | 45 | 96 | 46.4 | 99-104 | 41.5 | 78-80 |
| 180×180 | 50 | 91 | 42 | 115-120 | 41.7 | 88-90 |
| 200×200 | 40 | 87 | 46.9 | 81-82 | 43.0 | 68-70 |
| 200×200 | 50 | 77 | 37 | 115-120 | 42.0 | 88-90 |
| 230×230 | 35 | 75 | 46.7 | 72-76 | 37.0 | 50-67 |
| 250×250 | 30 | 72 | 49.7 | 63-64 | 30.0 | 48-49 |
| 250×250 | 35 | 67 | 43 | 76-78 | 32.0 | 59-61 |
| 250×250 | 40 | 62 | 49.7 | 82-86 | 34.0 | 50-80 |
| 270×270 | 35 | 59 | 39.4 | 76-80 | 30.0 | 58-70 |
| 290×290 | 20 | 68 | 41.7 | 43-44 | 18.4 | 29-30 |
| 300×300 | 30 | 55 | 38 | 66-68 | 28.0 | 40-59 |
| 325×325 | 23 | 55 | 49.8 | 49-53 | 25.4 | 38-39 |
| 325×325 | 28 | 50 | 41.2 | 63-64 | 26.4 | 50-51 |
| 325×325 | 30 | 48 | 38 | 66-68 | 24.0 | 40-59 |
| 350×350 | 25 | 48 | 43 | 52-54 | 18.7 | 41-50 |
| 400×400 | 18 | 46 | 51.3 | 36-40 | 20.0 | 28-30 |
| 400×400 | 23 | 41 | 40.7 | 50-54 | 19.0 | 35-48 |
