| Model Number: | HH-SSDW |
| MOQ: | 1 square meter |
| Payment Terms: | L/C,T/T,Western Union |
| Supply Ability: | 1000 ROLLS PER 30 DAYS |
| Mesh | Wire Diameter, inch (Warp x weft) | Reference values of particles flown |
|---|---|---|
| 12 x 64 | .023 x .0165 | 180 |
| 20 x 250 | .0010 x .008 | 87 |
| 24 x 110 | .014 x .010 | 115 |
| 30 x 150 | .009 x .007 | 95 |
| 30 x 160 | .009 x .007 | 90 |
| 30 x 250 | .010 x .008 | 70 |
| 40 x 200 | .007 x .0055 | 75 |
| 50 x 250 | .0055 x .0045 | 60 |
| 80 x 700 | .004 x .003 | 35 |
| 120 x 180 | .004 x .0035 | 75 |
| 120 x 200 | .004 x .0031 | 70 |
| 120 x 400 | .0039 x .0026 | 40 |
| 120 x 600 | .0039 x .0023 | 28 |
| 165 x 800 | .0028 x .0020 | 25 |
| 165 x 1200 | .0028 x .0016 | 19 |
| 165 x 1400 | .0028 x .0016 | 14 |
| 200 x 600 | .0024 x .0018 | 26 |
| 200 x 900 | .0023 x .0016 | 23 |
| 200 x 1400 | .0028 x .0016 | 10 |
| 250 x 1370 | .0022 x .0015 | 8 |
| 250 x 1400 | .0022 x .0015 | 8 |
| 250 x 1620 | .0022 x .0015 | 7 |
| 325 x 1480 | .0014 x .0012 | 7 |
| 325 x 1700 | .0014 x .0012 | 6 |
| 325 x 1900 | .0014 x .0011 | 5 |
| 325 x 2300 | .0014 x .0010 | 5 |
| 325 x 2800 | .0014 x .0010 | 4 |
| 375 x 2400 | .0012 x .0009 | 4 |
| 400 x 2800 | .0011 x .00078 | 2 |
