| Model Number: | HH-Multi Cartridge Filter |
| MOQ: | 1 pcs Multi Cartridge Filter |
| Price: | contact with us |
| Payment Terms: | L/C, T/T, Western Union, Alipay |
| Supply Ability: | 100000 pcs per 30 days |
| Model # | Cartridge Requirements | Pipe Size (flange) | Max. Flow Rate (GPM) | Drain Size (NPT) |
|---|---|---|---|---|
| 1 | (4) of 10" | 2" | 24 | 1/2" |
| 2 | (4) of 20" | 2" | 48 | 1/2" |
| 3 | (4) of 30" | 2" | 72 | 1/2" |
| 4 | (4) of 40" | 2" | 96 | 1/2" |
| 5 | (5) of 10" | 2" | 30 | 1/2" |
| 6 | (5) of 20" | 2" | 60 | 1/2" |
| 7 | (5) of 30" | 2" | 90 | 1/2" |
| 8 | (5) of 40" | 2" | 120 | 1/2" |
| 9 | (6) of 40" | 3" | 144 | 1/2" |
| 10 | (7) of 20" | 2" | 84 | 1/2" |
| 11 | (7) of 30" | 2" | 126 | 1/2" |
| 12 | (7) of 40" | 3" | 168 | 1/2" |
| 13 | (9) of 40" | 3" | 216 | 1/2" |
| 14 | (12) of 40" | 4" | 288 | 1/2" |
| 15 | (22) of 30" | 4" | 396 | 1/2" |
| 16 | (22) of 40" | 6" | 528 | 1/2" |
| 17 | (27) of 40" | 6" | 660 | 1/2" |
| 18 | (36) of 40" | 6" | 720 | 1/2" |
| 19 | of 40" | 6" | 1,008 | 1/2" |
| 20 | of 40" | 8" | 1,320 | 1/2" |
| 21 | (61) of 40" | 8" | 1,464 | 1/2" |
| 22 | of 40" | 8" | 1,752 | 1/2" |
| 23 | of 40" | 10" | 2,340 | 1/2" |
| 24 | of 40" | 10" | 2,880 | 1/2" |
| 25 | of 40" | 10" | 3,000 | 1/2" |
| Max. Temperature | 130℃ |
| Max. Pressure | 10 Bar (150psi) or according to requirement |
| Recommended Pressure | ≤ 8 Bar (115psi) at 25℃ |
