Galvanized Steel Solar Panel Bird Mesh UV Stabilized PVC Coating

Model Number:	HH-SPM
MOQ:	one rolls mesh
Price:	contact us to get lowest price
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	5000 rolls protection Blocker Mesh per 30 days

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001-2015

Name:

Solar Panel Bird Mesh

Meah Type:

Weld Steel Wire Mesh

Wire Diameter:

19-gauge

Opening:

1/2"

Package Size:

31*31*17cm/12.2*12.2*6.67in

Finished:

UV-stabilized PVC Coating

Fasteners:

J Hook And Self Locking Washer

Advantage:

Smooth Edges And Long Life

Packaging Details:

roll + carton+ pallet for protection Blocker Mesh

Supply Ability:

5000 rolls protection Blocker Mesh per 30 days

Highlight:

Galvanized Steel Solar Panel Bird Mesh

Solar Panel Bird Mesh UV Stabilizedh

Solar Panel Bird Mesh PVC Coating

Product Description

Solar Panel Protection Blocker Mesh

Description

Our 19-gauge 1/2"-opening galvanized steel Solar Panel Protection Blocker Mesh is coated in a black, UV-stabilized PVC coating that blends in with the shaded area below the solar panel array to provide long-lasting protection against birds and critters. The mesh can be cut and bent into custom shapes and secured to the solar panels with our solar panel clips or Bird Barrier Bond.

Specifications

	In Metric	In Imperial
Wire Diameter	0.7/0.8/0.9/1.0/1.1/1.2 mm	16Ga., 19Ga.
Mesh Opening	12.7 × 12.7 mm, 25.4 × 25.4 mm, 12.7 × 25.4 mm	1/2" × 1/2", 1" × 1", 1/2" × 1"
Width	0.1/0.15/0.2/0.23/0.25/0.3 m	4", 6", 8", 9", 10", 12"
Length	15/20/25/30 m	50', 66', 82', 100'

Key Features

PVC Coated Material: Made of galvanized welded steel mesh coated with black PVC for maximum weather resistance, rust resistance, and UV protection.
1/2 Inch Grid: Allows wind and water flow while preventing bird entry, protecting roof, wires and equipment.
Complete Accessories: Kit includes 100 aluminum fasteners, protective gloves, and heavy-duty scissors.
Easy to Install: Malleable material can be easily cut to size and quickly installed under panels or in corners.
Smooth Edges: Protects from scratches during installation.
Durable Fasteners: Corrosion-resistant aluminum fasteners provide secure attachment.
Application: Protects solar panels from damage by birds and rodents.
